Our store offers a curated selection of genuine Japanese products. You can shop with complete peace of mind knowing that all our items are authentic. Please note that the instructions and manual for this product may only be available in Japanese.
1. KEY FEATURES:
- Measuring range (mm): 0~300
2. PRODUCT DESCRIPTION:
[Features] - The character height on the LCD display has been expanded to 11.0 mm, improving visibility (approx. 16% higher than the manufacturer).•ABS (absolute) scale eliminates the need to set the origin every time the power is turned on.•The parallelism of the measurement surface is less likely to go awry than the main scale width of 20 mm NI.- Achieved a battery life of approximately 5 years (18,000 continuous hours) under normal use.•The battery cover does not require screws, ensuring easy and speedy battery replacement and confidentiality.•With coolant proof IP68, it is unaffected by contamination such as cutting oil, water, and oil, and can be used in the same environment as the analog type.[Specifications] •Measurement range (mm: 0~300 •Minimum display amount (mm): 0.01 •Instrumental error (mm): ±0.03 •Repeatability (mm): 0.01 •Thumb roller: Available •Data output: Available •Power source: Silver oxide battery (SR44) x 1 •Battery life: Approximately 5 years (in normal use) •Position detection method: Electromagnetic induction absolute encoder method •Response speed: Unlimited•Liquid crystal display: 7 segments, 5 digits, negative, character height 11, 0mm •Function: Origin setting (ORIGIN), auto power on/off function, data output •Alarm device: Voltage drop, scale contamination error, overflow error •Using temperature (℃): 0~40 •Storage temperature (℃): -10~60 •Protection grade: IP67 [Notes] •Instrumental error does not include quantization error.•Data output can be output externally using a connection cable (with DATASY power switch).•The auto power on/off function will turn off the display after about 20 minutes, and the power will turn on automatically when you move the slider.
3. PRODUCT DIMENSIONS & WEIGHT:
- Weight: 0.8 kg
- Dimensions: 46.6 x 14.0 x 3.8 cm
4. SPECIFICATIONS:
