Need to make molds or samples, create products and DIY process soft metals Being curious about making crafts Try this professional 9 in 1 motorized multipurpose machine which inclues functions of metal lathe, miller, sawing machine, wood turner, sanding machine, driller, handheld machine (sanding/ drilling/ milling). It's perfect for processing plastic, models, soft metal and wood.
Features:
Mini 9 in 1 multipurpose machine for DIY assembly of metal lathe, miller, sawing machine, wood turner, sanding machine, driller, handheld machine (sanding/ drilling/ milling).
Great handcraft tool kit for DIY, hobby, model making, crafts, students, small parts processing, etc.
Made of high quality metal and plastic, durable and non-deformable for usage.
Interesting to install and use, perfect gift for lathe DIY enthusiasts. Compact size, suitable for home use.
This mini multipurpose machine can be assembled into 9 kinds of different lathes, but you can use only one kind of these lathes at the same time.
Specifications:
Plug: EU/ US (Optional)
Input Voltage: 100-240V, 50/60Hz
Output: 12V 3A
Color: Black + Red
Material: Metal + Plastic
Motor Rotation Speed: 20000rpm
Motor Voltage/ Current: 12V 5A
Big Slider Travel: 150mm / 5.91in
Small Slider Travel: 35mm / 1.38in
Package Size: 51.5 * 35 * 8.5cm / 20.28 * 13.78 * 3.35in
Package Weight: 3380g / 7.45lbs
6-in-1 Functions:
--Wood Turning Lathe
Center Height: 27.5mm / 1.08in
Distance between Centers: 135mm / 5.31in
--Sawing Machine
Stroke of Jig Sawblade: 5mm
Workbench Size: 130 * 110mm / 5.12 * 4.33in
Applicable Material and Depth: Hardwood 4mm, Tri-ply Wood 7mm, Corkwood 18mm, Thin Aluminum Sheet 0.5mm, Organic Glass 2mm
--Sanding Machine
Diameter of Sanding Paper Panel: 55mm / 2.17in
--Metal Lathe
Center Height: 27.5mm / 1.08in
Distance between Centers: 135mm / 5.31in
--Drilling Machine
Travel Scope: X=25, Y=150, Z=32
--Milling Machine
Travel Scope: X=25, Y=150, Z=32
Machine Vice Clamping Range: 52mm / 2.05in
Package List:
1 * Long Machine Bed
1 * Short Machine Bed
1 * Work Bench
1 * Tailstock
1 * Big Slider
1 * Belt Cover
1 * Motor
1 * Motor Gearbox
1 * Jigsaw Casing
1 * 3-Jaw Chuck
1 * Machine Vice
1 * Woodturning Support
1 * Right Angle Reinforcing Plate
1 * Intermediate Piece
2 * Small Slider (A/ B)
1 * Screwdriver
1 * Handheld Turning Tool
1 * Sand Wheel
1 * Power Transformer (US+EU)
1 * Lever for Drilling/ Milling
6 * Copper Collet (1-6#)
2 * Inner Hex Spanner (2mm/ 1.5mm)
4 * Connection Piece
2 * 3-Jaw Chuck Locking Lever
1 * Tool for Turning 4.0
1 * Milling Cutter (4mm)
1 * Drill Bit (3mm)
1 * Collet Nut
14 * Slider Nut
1 * Lathe Tool Press Lock
1 * Eccentric Wheel
1 * Drive Center
1 * Nut
8 * Jig Sawblade
4 * Plain Washer (4*14*0.8mm)
2 * Sanding Paper
1 * Belt
1 * Center Finder
21 * Screw (M4*16/ 14/ 12/ 10/ 8mm)
